Technical Specification

     System Resource
     Main Chipset :::     GX6701
     Tuner Type :::      RT850 (DVB-T/T2)
     Flash Memory :::      32Mbit
     DDR RAM :::      512Mbit

     Tuner & Demodulation (DVB-T/T2)
     Frequency Range :::      48~862MHz
     Input Symbol Rate :::      1.0~7.0Mbps
     RF Input Level :::      -85dBm ～ -25dBm
     Constellations :::      QPSK, 16QAM, 64QAM, 256QAM
     Guard Intervals :::      1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256
     Demodulation :::      1K, 2K, 4K, 8K, 16K, 32K
     Code Rate :::      1/2, 3/5, 2/3, 3/4, 4/5, 5/6
     Antenna Power Output :::     DC 5V at max 75mA, Overload Protection

     Tuner & Demodulation (DVB-C)
     Frequency Range :::     48~862MHz
     Input Symbol Rate :::     3.6~7.0Mbps
     RF Input Level :::     -85dBm ～ -25dBm
     Constellations :::      16QAM, 64QAM, 128QAM, 256QAM

     A/V Decoding
     Transport Stream :::      MPEG-2, MPEG-4/H.264
     Input Rate :::      Max. 120Mbit/s
     Audio Decoding :::      MPEG-1 Layer I/II, MPEG-2 Layer II, Dobly
     Audio Mode :::      Left/Right/Stereo/Mono
     Sampling Rate :::      32KHz、44.1KHz、48KHz
     Video Decoding :::      MPEG-2 MP@ML, MPEG-4/H.264 MP&HP and ML&HL
     Video Resolution :::      1080p, 1080i, 720p, 576p, 576i, 480p, 480i
     Aspect Radio :::      4:3, 16:9, Auto, LetterBox, Panscan

     Software and Application
     OSD Language :::      Multi-language
     CAS :::      None
     EPG :::     7 Days EPG
     Subtitle :::      Yes
     Teletext :::      Yes
     LCN :::      Yes
     Favorites :::      8 Fav Groups
     Timer :::      Yes
     NIT Search :::      Yes
     Soft Upgrade :::      USB/OTA/Internet
     Sort Channel :::      Yes
     Channel Editor :::      Yes
     Parental Control :::      Yes
     USB PVR/TimeShift :::      Yes
     USB Disk format :::      FAT, FAT32, NTFS
     USB Wi-Fi Dongle :::      Ralink 5370/7601
     3G Dongle :::      None
     TS Recorder :::      None
     Multimedia Support :::     .mkv/.avi/.mp4/.mov/.ts/.asf/.flv/.wmv/.vob./dat/.mp3/.wma/.jpg/.png/.bmp/.gif
     Network Application :::      Youtube/Weather/Google Map/RSS/IPTV/Megogo/Xstream/Stalker/OTT
     Others :::       None

     A/V & Data Input/Output
     Power Supply :::      5V/1.5A Power Adaptor
     Tuner Interface :::      ANT IN/LOOP OUT
     HDMI :::      Type A
     USB :::      2*USB 2.0 Port
     AV/SCART :::      3RCA or Mini-Jack for CVBS+R/L Audio
     Display :::      4*7 LED Display
     S/P DIF :::      None
     RS-232 :::      None
     RF Modulator :::      None
     Buttons :::      Power, CH+/CH-
     Card Reader :::      None
     Ethernet :::      None

     Accessories
     Giftbox :::      Yes
     Adaptor :::      Yes
     Battery :::      Yes
     IR Remotel Control :::     Yes
     User Manual :::      Yes
     AV Cable :::     Yes
     HDMI Cable :::     Optional
     Wi-Fi Dongle :::      Optional

     Loading
     Machine Size :::     148*80*35mm
     Packaged Size :::     170*150*48mm
     Machine Weight :::     0.35Kg
     Packaged Weight :::    0.45Kg
     PCS/CTN :::     20PCS
     CTN Size :::     360*265*320mm
