Technical Specification

     System Resource
     Main Chipset :::     GX6605S
     Tuner Type :::      AV2018
     Flash Memory :::      32Mbit
     DDR RAM :::      512Mbit

     Tuner & Demodulation (DVB-S/S2)
     Frequency Range :::      950 ~ 2150MHz
     Input Symbol Rate :::      2~90MSPS
     RF Input Level :::      -65dBm ～ -25dBm
     Constellations :::      QPSK, 8PDK, 16PSK
     Code Rate :::      1/2, 1/3, 2/3, 1/4, 3/4, 2/5, 3/5, 4/5, 5/6, 8/9, 9/10
     Input Impedance :::      75Ω
     Antenna Power Output :::      13V, 18V, Auto, Overload Protection

     A/V Decoding
     Transport Stream :::      MPEG-2, MPEG-4/H.264
     Input Rate :::      Max. 120Mbit/s
     Audio Decoding :::      MPEG-1 Layer I/II, MPEG-2 Layer II, Dobly
     Audio Mode :::      Left/Right/Stereo/Mono
     Sampling Rate :::      32KHz、44.1KHz、48KHz
     Video Decoding :::      MPEG-2 MP@ML, MPEG-4/H.264 MP&HP and ML&HL
     Video Resolution :::      1080p, 1080i, 720p, 576p, 576i, 480p, 480i
     Aspect Radio :::      4:3, 16:9, Auto, LetterBox, Panscan

     Software and Application
     OSD Language :::      Multi-language
     CAS :::      Optional
     EPG :::     7 Days EPG
     Subtitle :::      Yes
     Teletext :::      Yes
     LCN :::      Yes
     Favorites :::      8 Fav Groups
     Timer :::      Yes
     NIT Search :::      Yes
     Soft Upgrade :::      USB/OTA/Internet Network
     Sort Channel :::      Yes
     Channel Editor :::      Yes
     Parental Control :::      Yes
     USB PVR/TimeShift :::      Yes
     USB Disk format :::      FAT, FAT32, NTFS
     USB Wi-Fi Dongle :::      Ralink(MTK) 5370
     3G Dongle :::      Huawei, ZTE
     TS Recorder :::      Yes
     Multimedia Support :::     .mkv/.avi/.mp4/.mov/.ts/.asf/.flv/.wmv/.vob./dat/.mp3/.wma/.jpg/.png/.bmp/.gif
     Network Application :::      OTT (m3u file update by internet)
     Others :::       TKGS, Biss, PowerVU, Tandberg, Import m3u from USB

     A/V & Data Input/Output
     Power Supply :::      12V/1.0A Power Adaptor
     Tuner Interface :::      LNB IN
     HDMI :::      Type A
     USB :::      USB 2.0 Port
     AV/SCART :::      3RCA for CVBS+R/L Audio
     Display :::      4*7 LED Display with IR Extender
     S/P DIF :::      None
     RS-232 :::      Yes
     RF Modulator :::      None
     Buttons :::      None
     Card Reader :::      Optional
     Ethernet :::      None

     Accessories
     Giftbox :::      Yes
     Adaptor :::      Yes
     Battery :::      Yes
     IR Remotel Control :::     Yes
     User Manual :::      Yes
     AV Cable :::     Yes
     HDMI Cable :::     Optional
     Wi-Fi Dongle :::      Optional

     Loading
     Machine Size :::     120*75*28mm
     Packaged Size :::     145*95*75mm
     Machine Weight :::     0.1Kg
     Packaged Weight :::     0.3Kg
     PCS/CTN :::     36PCS
     CTN Size :::     465*305*310mm
